ELECTRICAL CHARACTERISTICS PER IGBT LEG
Tj 25°C (UNLESS OTHERWISE SPECIFIED)| SYMBOL | PARAMETER | MIN | TYP | MAX | UNIT |
|---|---|---|---|---|---|
| BVCES | Collector to Emitter Breakdown Voltage | 600 | - | - | V |
| IC | Continuous Collector Current | - | - | 30 | A |
THERMAL AND MECHANICAL CHARACTERISTICS
| SYMBOL | PARAMETER | MIN | TYP | MAX | UNIT |
|---|---|---|---|---|---|
| RθJB_I | IGBT Junction-to- Base Plate Thermal Resistance Per Leg | - | - | 1 | °C/W |
| TJ | Operating Junction Temperature | -55 | - | 150 | °C |
| TSTG | Storage Temperature | -55 | - | 150 | °C |
Package type : SIP4-11L
